Horizontal Tank Welding Machine with Girth Seam Welder

Color:customized
Material:stainless steel
Min order:1
Availability:
Quantity:
  • NSHW-I
  • WINCOO
Product Description

Product introduction

WINCOO Engineering offers the Automatic Girth Welder for tank fabrication applications.Unlike current girth welders on the market,the MSHW series comes standard with a Dual Drive System.This self-propelled submerged arc welding system can reduce field storage tank welding time up to 40%.Weld defects are greatly reduced,saving tank erection costs.The Girth Welder is applicable for top down or bottom up construction single or double wall storage tanks for inside and outside welding.There are four standard units,however our design allows us to offer custom built units for non-standard application.

Product parameter

Welding Process

SAW

Model

MSHW-I

Plate Thickness

8 – 45mm

Plate Material

Carbon steel, Stainless Steel

Groove

K groove

Seam Position

Girth weld

Min Tank Diameter

Φ5.0m

Plate Width

1.5 – 2.5m

Power Input

380V/3PH/50HZ

Erection Method

Bottom To Top

Dimension(L x W x H)

1460mm x 988mm x 2760mm(if design change, will as per new   design)

Gross Weight

800kg

Product main configuration

参数图片

参数图片-2

参数图片-3

横焊机结构图片

Product pictures

工厂图片横焊机细节图片
