What Is

Tank Hydraulic Jacking System

Tank hydraulic jacking system is a new type of equipment which is powered by hydraulic oil and specially used for jacking large storage tanks.And we are the professional tank hydraulic jacking system manufacturers.


The Application Of Tank Hydraulic Jacking System

Tank hydraulic jacking system with high accuracy is a large-scale equipment specially designed for the national oil reserve project developed suitable steel giant silo tank inversion welding process engineering.
Uses: steel giant silo tank inversion process of welding engineering.
Use either:
 vertical lift displacement of the overall structure, the overall building.   large span roof truss and flip construction of multi-storey buildings.
large objects vertical lifting, lifting.


How To Operate The Tank Hydraulic Jacking System

Operation Principles for Lifting by Inverted Method
1. LYT-type hydraulic hoist is used to firstly lift the tank roof and the top (first layer) siding of the tank. It’s required to group weld tank siding when the lifting height of siding exceeds the second siding (the second layer from the top) by 30-50mm, and group weld the third layer (the third layer from the top to the bottom) of the tank after lifting again, lift successively, group weld the siding of the tank layer by layer, until the last layer of siding.
2. LYT-type hydraulic hoist is used for lifting. When oil enters the hydraulic jack, the movable pulley is pushed upward by pressing the piston, thus driving the load-bearing chain to lift the expansion ring. In this way, the whole tank (including tank roof) is lifted up, until it reaches the pre-set height (there is a voidance of the next layer of plate). The siding in this layer is surrounded for butt welding. After the positioning block is welded, hydraulic hoist returns and the lift tank falls back to the newly-surrounded siding. After welding of circular seam and vertical seam, the door-type card for fixing expansion ring is cut off and the expansion ring is released. In this way, the hoist returns and expansion ring falls to the Model of hydraulic pump station Tank volume Rated pressure Rated flow Power Control voltage of solenoid valve Motor drive rate YB-7.2 220L (700*550*580) 25Mpa 7.2L/min Three-phase Four-wire (380V) 220V 5.5KW YB-14.5 340L (750*650*650) 25Mpa 14.5L/min 220V 7.5KW Mode of LYT-type hoist Rated lifting capacity (KN) Hydraulic area (mm) Rated oil pressure (MPa) Piston stroke (mm) Chain stroke (mm) Cylinder safety equipment Reinforcement measures LYT-120-2700 120 11304 25 1500 2700 Double-direction oil-way hydraulic lock 2 adjustable pull rods LYT-200-2700 200 18859.6 25 1500 2700 Double-direction oil-way hydraulic lock 2 adjustable pull rods LYT-300-2700 300 25434 25 1500 2700 Double-direction oil-way hydraulic lock 2 adjustable pull rods bottom of tank siding. Then, the next circular plate is expanded and transfer rib plate, such as door-type card, is welded for lifting, and so forth. The group welded tank is lift, until group weld of the last layer of siding, so that the whole storage tank is installed with this inverted method.


Professional Tank Hydraulic Jacking System Manufacturers

For the tank hydraulic jacking system, we has been sold more than 20 countries in more than 1000 projects sites. We have confidence for the machine quality and after sale service. We can provide Advanced three-stage type、Advanced two-stage type、Simple chuck type、Simple chain type.In Middle East, we have sold to UAE, Saudi Arabia, Oman, Bahrain, Kuwait. In Africa, we have sold machine to Cameron, Sudan, Egypt, Senegal, Nigeria,Zambia,Ethiopia,Senegal,etc. We have sold to vietnam, Indonesia , Malysia,Philippines,Singapore, Mexco,Mogulia, Russia,etc.We are the professional tank hydraulic jacking system manufacturers, if you are interested in us,contact us!

SSA hydraulic jacking certificate
SSA Hydraulic Jacking Certificate

Why Choose Us

Wincoo Engineering Co., Ltd (WINCOO) is engaged in bringing the most suitable solutions/equipments for client, fabricators, EPC/C companies on pipe fabrication, tank construction, pipeline construction,industrial production lines, clean energy project and other industrial field.

We have ability of providing workable solutions to support clients to be awarded with shorter project execution time, fewer man-hour cost and higher efficiency construction/fabrication method and better quality during phase of project bidding.Based client's facility/site space availability, we are able to study/design and present matched configurations on project schedule, quality, cost and productivity to guarantee production pace is accordance with project requirement.To support project execution, we are always ready to work as fireman to give prompt supply on project materials from different consumables, tools, equipments/machines to special merchandise. With flexibility, we are also glad to perform as procurement agent in China to seek required supply resources.


Information About Tank Hydraulic Jacking System


Support you to win the project during bidding phase. We can provide your more suitable configurations to help you shorten the constrcution time.

We can provide all technical documents and advices to support you for construction procedure clearifications.

We can calculate the most suitable number of hydraulic jack according to the weight of the tank.

We can provide your suitable hydraulic jack accessories with much more competetive price from our long time business partner if you need.

We can provide site people training service, and operation service or manpower service or as a subcontractor.
