Best Price And High Efficiency Tank Jacking System for Oil Tank

Color:Red or Customized
Material:Stainless steel
Min order:1 set
Availability:
Quantity:
  • YT-C Series
  • WINCOO
YT-C type Advanced Hydraulic Jack

Introduction of Jack

YT-C type hydraulic storage tank lifting equipment is a set of large hydraulic lifting equipment specially developed by our company for national crude oil reserve project in 1994.As long as the number of hydraulic cylinder and pump station system is increased or decreased, this type of equipment can be applied to the inverted construction of large storage tanks with different volumes ranging from thousands of cubic meters to hundreds of thousands of cubic meters.

The control part adopts Siemens PLC modular design concept, simple operation, reliable quality.The hydraulic cylinder can be used for single or multiple lifting height adjustment, and can also be used for centralized control of multiple groups.Through more than ten years of practice summary, we continue to optimize the equipment, improve the production process, so that the product quality and performance greatly improved, the majority of users praise.

The overall structure of the equipment and its working principle

The overall structure of the equipment

1, The equipment is evenly placed inside the jacked tank. The overall force and lateral force of the equipment are calculated strictly and successfully applied.

2, The structure is rigorous and compact, the output force is adjustable, the jacking speed meets the jacking requirements, and the synchronization accuracy is high.

Working principle of the equipment

The transfer of force: output force of hydraulic cylinder → steel wire rope → rising ring (welded with lifting lug) → rib plate for transferring force → tank wall jacking

Jacking control process:

1, Pump station control box (rotating selection button) → Centralized control operation box (Figure 1-3) → hydraulic jacking pump station (solenoid of valve group) →PLC devices → centralized control operation box → hydraulic jacking pump station → integral or partial lifting or lowering of hydraulic cylinder.

2, Pump station control box (rotating selection button) → control handle → hydraulic cylinder (single or multiple) fine adjustment up and down.

1

Outline drawing of jack

2

Layout of equipment

3

Hydraulic station scheme drawing

Main features of Hydraulic jacks:

1, The system consists of hydraulic pump station, cylinders and steel wire. Easy to installation and operation;

2, The system utilizes PLC central control to handle lift. Each power pack is equipped with auxiliary balance device to guarantee the precision of simultaneously lifting;

3, Hydraulic lift pump station has subsidiary manual control and central control two operation models. The cylinder can be adjusted to lift separately or to lift with several others as one group, and multi groups can also be integrated to lift reach better precision and better welding effect;

4, All the cylinders are with safety valve. It can be automatically locked to avoid cylinder/ tank dropping even under situation of power off, high-pressure hose broken, burst;

5, The cylinder is with one high pressure hose to avoid oil leaking that usually happen by the traditional multiple hoses. Cylinder will return to initial condition by itself weight;

6, Stroke of Hydraulic cylinder is various as per tank plate width, which can satisfy each annular shell plate one-step lift. Greatly reduce the time waste;

7, Hydraulic cylinder basic height is based on the tank shell width, which can match automatic girth welding machine to proceed internal girth seam welding;

8, Module configuration, the jacking system quantity can be adjusted as per different size of tank and weight;

9, High efficiency, each time lifting or falling down only needs around 15 minutes;

10, Can well cooperate with our tank welding machines, which can greatly reduce the manpower cost and reduce the construction time.

Model and parameter of Jack

Model/Parameter

Max   service pressure

Max   output force of single hydraulic cylinder

Max   stroke of hydraulic cylinder

Hydraulic   cylinder lifting speed

Oil   pump flow

Motor   speed

Motor   voltage

Motor   power

Working   environment temperature

YT10-2200C

24Mpa

10T

1250mm

190mm/min

14.4L/min

1440r/min

~380V

5.5kw

-15~50   ℃

YT10-2700C

31Mpa

10T

1400mm

270mm/min

7.2L/min

1440r/min

~380V

5.5kw

-15~50   ℃

YT12-2700C

31Mpa

12T

1400mm

250mm/min

7.2L/min

1440r/min

~380V

5.5kw

-15~50   ℃

YT18-1700C

24Mpa

18T

1240mm

175mm/min

7.2L/min

1440r/min

~380V

4kw

0~50℃

YT18-2000C

24Mpa

10T

1240mm

175mm/min

7.2L/min

1440r/min

~380V

4kw

0~50℃

YT18-3000C

25Mpa

18T

1600mm

187mm/min

7.2L/min

1440r/min

~380V

5.5kw

-10~60℃

YT25-2700C

31.5Mpa

25T

1650mm

175mm/min

7.2L/min

1440r/min

~380V

5.5kw

-10~60℃

YT25-3000C

29Mpa

25T

3200mm

160mm/min

7.2L/min

1440r/min

~380V

4kw

-10~60℃

YT30-2700C

29Mpa

30T

2050mm

130mm/min

7.2L/min

1440r/min

~415V

4kw

-10~60℃

Construction site photos

现场图片8

Company profile

Wincoo Engineering Co.,ltd is a hydraulic machinery manufacturing company integrated with design, development, production and sales, which mainly manufactures YT three-stage hydraulic jack, YT-C type hydraulic jack,LYT-type chain-type hydraulic hoist, SQD unfixing holding-latch hydraulic hoist and supporting products. Such products are mainly used for inverted lifting and installation of steel storage tanks. Founded in 2003, after years of concentrated scientific research and development, the company obtained the patent certificate of "Utility Model Hydraulic Hoist’ issued by "China National Intellectual Property Administration", and the right to use the trademark of "WINCOO" in 2008, so as to enable products of Wincoo Engineering Co.,ltd to quickly become Chinese brands.

 Since entering Chinese market for more than 10 years, products of Wincoo Engineering Co.,ltd has been sold in nearly thirty provinces, cities and autonomous regions in China, and some overseas markets. The company has production line of advanced technology; meanwhile, Wincoo Engineering Co.,ltd designs, develops and processes products for famous domestic installation companies. With professional team, strict management and excellent equipment, the company strives to create the brand of "WINCOO", hydraulic hoist and series supporting products. As an expert of hydraulic hoist, WINCOO with charm of high technology is keen, innovative and forging ahead to establish design language of the company. In an all-inclusive and absorbing and open-minded manner, the hydraulic hoist and hydraulic pump station are perfectly combined to form hydraulic lifting equipment (hydraulic jacking equipment). As the founder and disseminator of hydraulic hoist, WINCOO has been building the inverted hydraulic lifting equipment and production technology of Dongfang installation engineering for a long time.

 Wincoo Engineering Co.,ltd is committed to the research and development of YT three-stage hydraulic jack, YT-C type hydraulic jack,LYT-type chain-type hydraulic hoist, SQD-type unfixing holding-latch hydraulic hoist and the supporting equipment. These type products have been widely used in various projects (inverted lifting, translation, jacking, and climbing, etc.) by major installation companies all over the country, and have achieved satisfactory results.

 WINCOO sticks to improve core competitiveness by virtue of corporate culture, thus setting a good social image of the company during development. "Those hoping to expand the company must study hard from the moment, and the pursuit is endless". "WINCOO" will continuously forge ahead, contributes to the course of installation project in China and permanently moves forward to forge the monument of hydraulic lifting industry in China.

What we can do for you?

1. Support you to win the project during bidding phase. We can provide your more suitable configurations to help you shorten the constrcution time.
2. We can provide all technical documents and advices to support you for construction procedure clearifications
3. We can calculate the most suitable number of hydraulic jack according to the weight of the tank
4. We can provide your suitable hydraulic jack accessories with much more competetive price from our long time business partner if you need.
5. We can provide site people training service, and operation service or manpower service or as a subcontractor.
