Automatic CNC Gouge And Grinding Machine for High Alloy Steel Boiler

The machine consists of CNC cross manipulator, multifunctional powerful grinding abrasive wheel and belt head, dust removal system,electronic system and pneumatic control system.

Product Description

CNC Gouge and Grinding Machine
Circumferential and Longitudinal Seam Gouge and Grinding Machine

    The machine consists of CNC cross manipulator, multifunctional powerful grinding abrasive wheel and belt head, dust removal system,electronic system and pneumatic control system.
* Carbon steel , Stainless steel circumferential seam gouge, grinding and polishing.
* Vessel internal stainless steel cladding welding layer grinding and polishing
* Vessels internal and external circumferential, longitudinal seam, weld reinforcement part grinding and polishing. Use before vessel fitting-up.
* V bevel type vessel.

Product parameter

Workpiece   Diameter ranges


Minimum Diameter   required while with Dust removal system

≥φ1400mm(Internal   longitudinal welding reinforcement part grind required minimum Diameter   ≥φ2400mm,If less than φ2400mm, needs to notice before manufacturing)

Maximum   workpiece/vessel thickness

δ≤230 mm

Single section of   vessel maximum length

L≤4500 mm

Workpiece   materials


Width of welding   seam

≤90 mm

Surface roughness


Machine working   environment


Three phase AC   380±10%,50HZ±2%



Maximum humidity


* It consists of base hold, level adjustment unit, column, rotating device, power driving system, Mechanical locking mechanism,cross slider/carriage, beam and related moving system. Rotating device between Base hold and column is driving by electricity.
* Cross slider utilize reducer and Ball screw drive to control up and down. Beam front and back moving is driven by reducer motor and gear rack.
* Column and beam guide rails are the oversea imported heavy load straight guide. Beam both ends can be equipped with multifunctional and powerful abrasive wheel and belt,dust removal system while it is also considered to leave other grinding &gouge head interfaces.
* There is lift lugs beside column end which is a fixed type. Overhead head crane can lift without steel wire.
* Cross sliders are installed with dust protection unit.
* Staircases are provided on column for maintenance.
* The deflection can be removed by grinding & gouge head constant pressure relocation mechanism.
